LTECH D24 DMX Decoder 24 kanaler

24 x 4/5A. Maks 2880W, 12-24VDC inn

Varenr: 185399

Alt. varenr: D24

2 069,-eks. mva

Logg inn for å se dine nettopriser.
Ikke kunde? Søk om å bli kunde her.

Kanaler

Ikke på lager i Oslo. Ta kontakt for leveringstid.

Input Signal:DMX 512/RDM
Working Voltage:12-24VDC
Output Current:5A*24CH,Max.120A(12V)
4A*24CH,Max.96A(24V)
Output Power:24CH*(60-120W),Max.2880W(12V)
24CH*(48-96W),Max.2304(24V)
Control Modes:DIM/CT/RGB
PWM Frequency:300-18000Hz
DMX512 Socket:green terminal?XLR-3?RJ45
Dimming Curve: 0.1~9.9, Standard, Linear, Logarithmic
Grayscale level: 8 bit(256 levels)/16bit(65536 levels)
Optoelectronic Isolation:Yes
Protection: Short circuit, overtemperature, overcurrent protection, self-recoverable
Operating temperature: -30?~55°C
Protection Level: IP20
