B-PASS is a smart access panel designed for seamless, fast, and secure access to Auracast™ streams.
Even in dense environments, users can connect effortlessly using Tap-to-Access (NFC) or Scan-to-Access (QR code).
In sensitive environments, B-PASS ensures that only authorized listeners can access the audio.
- Secure access and control panel for Auracast™ streams
- Seamless access via NFC and QR code
- Passkey generation via NFC admin tag or API
- Adjustable security levels
- Single-cable installation over Ethernet
- Customizable branding and signage
- Desktop and wall-mounted installations
- Fully compatible with CASTER and RTX devices
System
- CPU: RK3568 Cortex-A55 Quad-Core
- RAM: 2GB
- Internal Memory: 16GB
- OS: Android 11
Display
- Screen: 8" LCD IPS panel
- Resolution1280×800
- Viewing angle: 85/85/85/85 (L/R/U/D)
- Contrast : 800
- Brightens: 300 cd/m2
- Screen scale / area: 16:10 / Display area: 172.224(H)x107.64mm(V)
Interfaces
- Wi-Fi: 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
- Ethernet (RJ45): 10/100/1000 Mbps Ethernet with PoE
- Bluetooth: Bluetooth 5.2
- NFC: Yes
- TF card slot: Supports up to 64 GB
- USB Ports: 2 × USB-A, 1 × USB-C
- Headset jack: 3.5mm earphone + microphone
- Power: DC power jack
Power
- DC In: 12V DC / 1.5A, center-positive
- PoE: IEEE 802.3at, PoE class 4, 25.5W
Mounting
- Wall-mounting: VESA 75 x 75 mm
Physical
- Weight : 647g (1.42 lbs)
- Shipping Weight: 1,110g (2.44 lbs)
- Color: Black
