2-way passive loudspeakers, 250 W AES, 124db SPL

Features:
Low frequency: 10'' woofer/2.6''v.c.
High frequency: 1'' driver/1.7''v.c.
Frequency response: 70-18000 Hz (±3dB)
Reproduction of voice and music for live and recorded performances
Birch plywood enclosure
For sound installations in environments requiring dynamics and sound pressure

LOUDSPEAKER
System type: passive 2 way

COMPONENTS
Low frequency: 10'' woofer/2.6''v.c.
High frequency: 1'' driver/1.7''v.c.

FEATURES
AES/program power: 250/500W
SPL max: 124dB @1m (free field)
ACOUSTICAL SPECIFICATIONS
Sensitivity: 94dB @1W/1m (free field)
SPL cont/peak: 118/124dB @1m (free field)
Frequency response: 70-18000Hz (±3dB)
Coverage angle HxV: 90x70°
Cross over frequency: 2000Hz
Protection: H.F. signal compression
Recommended amplifier up to: 500W /8Ohm

INPUT/OUTPUT CONNECTORS
Input signal: 4pole IN/OUT

CABINET CONSTRUCTION
Cabinet material: 15mm birchplywood
Sospension system: 6 point M8 eyebolt, fly track, 35 mm pole mount
Angle: 10° trapezoidal taper
Handles: 2 on side

PHYSICAL
Dimensions (WxHxD): 304x495x300mm
Weight: 15kgDAD Fusion is a line of 2-way loudspeakers designed for professional application as front/side-fill and stage-monitor, delivering flexibility, quality and sound pressure in typical professional audio environments.
