eCOMPACT4BT
Desktop and 19" rackmount 4-channel analogue mixer with Bluetooth wireless connection for professional installation.
Main features
- 4-channel analogue mixer, 1 channel adjustable Talkover
- 19" rack or desktop
- 4 mic inputs, 1 combo connector
- 48V phantom power
- 6 RCA stereo line inputs + 1 stereo mini-jack
- Class 1 Bluetooth (up to 25m range)
- Source selector per channel
- Selectable HPF for MIC inputs (100Hz)
- 3-band tone control
- 45mm faders
- ALT OUT send per channel
- USB charging port
- Balanced MAIN OUT (XLR)
- Stereo/mono switch
- SUB OUT (XLR) with LPF (150Hz)
- Front panel headphone output
- 3URMKIT rack accessory included
- Universal external PSU with interchangeable connectors
Technical specifications
- Inputs: 4 MIC ports, 6 ST LINE ports, 1 COMBO MIC front panel
- Input sensitivity: LINE 0dBV, MIC(BAL) -35dBV, AUX -10dBV, BT -10dBVFS
- CMRR: BAL inputs >75dB @1kHz
- Phantom voltage: +48VDC selectable
- Outputs: MAIN(XLR), SUB(XLR), ALT(RCA)
- Headphones: ST mini-jack 200mW
- THD+Noise: LINE <0.03%, MIC <0.06%, AUX <0.03%, BT <0.05%
- Tone control: 3-way, BASS 100Hz±15dB, MID 2kHz±15dB, TREBLE 10kHz±15dB
- Talkover: Yes
- Power supply: External
- AC mains: 100-240VAC + 17.5VDC PSU
- Power consumption: 15W
- Installation: Desktop, 19" rack 3RU
- Dimensions: 440x132x125mm
- Weight: 3.0kg
