'8 channel PixlBus controller: integrated PSU, KLUSTR and Lucenti technology
- 8x "pixlbus"output ports (data + power), 200W/24Vdc per port
- 400 RGBW pixels per port (= 8x BW-100, 16x BW-50, ...) @ 50Hz. 3200 RGBW pixels in total.
Protocol limit for 400x RGBW on one port is ~60Hz. - Ports can be individually enabled/disabled.
- Ports support hot-plugging of devices.
- Overload protection: for sustained load > 200W. Auto cut-off for peak loads.
- Short circuit detection: port will be disabled independent of other ports.
- Plastic M12 4-pin connector, push-lock
- Proprietary Lucenti "Pixlbus" protocol
- Art-Net I (broadcast) & II, 3, 4 (unicast)
- sACN/E1.31 multicast and unicast
- Effects: Internal library of customizable effects, can run standalone
- Auto discovery of multiple PixlDrive8Pro controllers and all connected PixlBus devices
- Auto generation of DMX patch
- Easy assignation of Fixture IDs
- Export MVR file from KLSTR application containing all fixtures, GDTF files, fixture IDs and mapping for use in console
