| Specifications |
| Components |
LF: 18?, 4? voice coil, Neodymiun magnet assembly |
| Frequency range |
30 Hz – 140 Hz (-10dB) |
| Frequency Response |
35 Hz – 125 Hz (± 3dB) |
| Max. SPL |
132 dB |
| Coverage Angle |
Omnidirectional |
| Power |
1400 W Class D with switching power supply & PFC |
| LF Amplifier |
1 x 1400 W |
| Processing |
96 KHz / 64 bit double precision DSP |
| Control |
User control interface with LCD |
| Control Connections |
USB (DSP programming) |
| AC Power |
90 – 264V. 50/60 Hz with PFC |
| AC Connections |
16A Neutrik powerCon TRUE1 with looping output |
| Finish |
High resistant water-based black paint |
| Material |
18mm Premium birch plywood |
| Dimensions (H x W x D) |
556 x 632 x 697 mm |
| Weight |
45 Kg (99 lbs) |
