General Information
Cap-Base: (P)SFC  [ (P)SFC]
Operating Position: P15  [ Parallel +/-15D or Horizontal(HOR)]
Main Application: Architectural
Life to 50% Failures (Nom): 2500 h
System Description: Double Ended

Light Technical

Color Code: 856
Luminous Flux (Nom): 250000 lm
Chromaticity Coordinate X (Nom): 330
Chromaticity Coordinate Y (Nom): 360
Correlated Color Temperature (Nom): 5600 K
Luminous Efficacy (rated) (Nom): 100 lm/W
Color Rendering Index (Nom): 90

Operating and Electrical

Power (Nom): 2500 W
Lamp Current (Nom):22.5 A
Ignition Supply Voltage (Min): 198 V

Controls and Dimming

Dimmable: No

Luminaire Design Requirements
Bulb Temperature (Max): 980 °C
Pinch Temperature (Max): 300 °C

Net Weight (Piece): 0.245 kg
