Ceiling speaker for recessed mounting. ideal for vocal announcements and reproduction of background music.

Features:
Ceiling speaker with coaxial tweeter placed on a bridge support.
Built-in line transformer with multiple output connections for 100 V constant voltage lines.
White ABS body and metal protection grid.
Quick and easy installation by a special holding system, with no need of screws or other fixing elements.

LOUDSPEAKER
System type: ceiling speaker

COMPONENTS
Low frequency: 5''
High frequency: 1''

FEATURES
AES/program power: 20/40W
Input 100 V: 5/10/20W

ACOUSTICAL SPECIFICATIONS
Sensitivity: 91dB @1W/1m (free field)
Constant voltage: 100 V
Frequency response: 100÷20.000Hz (±3dB)

INPUT/OUTPUT CONNECTORS
Input signal: terminal with wire

CABINET CONSTRUCTION
Cabinet material: ABS, Iron

PHYSICAL
Weight: 1.20kg
Diameter Ø: 203mm
Flush-mounting hole Ø: 170mm
Color: White - 9010RAL
