4 kanals constant voltage LED driver med manuelle justering for hver kanal

RGBW constant voltage LED RF controller, can also be used as a RGBW RF remote.
4 knob dimming, digital numeric display and easy key operation.
Match with RF 2.4G single zone or multiple zone RGBW remote control optional.
256 levels 0-100% dimming smoothly without any flash.
Built in 10 dynamic mode, include jump or gradual change style.
PWM frequency 250/500/2000/8000Hz selectable.
Logarithmic or linear dimming curve selectable.

Input voltage: 12-24VDC

Input current: 16.5A

Output voltage: 4 x (12-24VDC)

Output Power: 4 x (48-96W)

Output type: Constant voltage

For øvrige spesifikasjoner, se datablad under "lenker & dokumenter"
