| Specifications |
| Components |
LF: 12", 2.5" voice coil, Malt Cross Cooling System
HF: Multidriver system with wave guide, 1.4" aluminium voice coil with titanium diaphragm |
| Frequency range |
60 Hz – 20 KHz (-10dB) |
| Frequency Response |
70 Hz – 18 KHz (± 3dB) |
| Max. SPL |
128 dB |
| Coverage |
100º H x 18º V |
| Power |
1400 W Class D with switching power supply & PFC |
| LF Amplifier |
1 x 800 W |
| HF Amplifier |
1 x 600 W |
| Processing |
96 KHz / 64 bit double precision DSP with FIR filters |
| Control |
User control interface with LCD |
| Control Connections |
USB (DSP programming) |
| AC Power |
90 – 264V. 50/60 Hz with PFC |
| AC Connections |
16A Neutrik powerCon TRUE1 with looping output |
| Finish |
High resistant water-based black paint |
| Material |
15mm Premium birch plywood |
| Dimensions (H x W x D) |
357 x 632 x 484 mm |
| Weight |
28 Kg (62 lbs) |
