Active sub woofer 600W with 2x300 W/4 Ohm stereo output.
Features:
Low frequency: 2x8'' woofer/2'' v.c.
Frequency response: 40/200 Hz (±3dB)
Adjustable Crossover: LPF:80/120 Hz - HPF 22, 80,125 Hz
Can be used with full range speakers in the ARK series.
Possible combinations ARK1200SA + 2 x ARK105 / 106 / 205 / 206, up to 4 for each channel.
Birch plywood enclosure.
LOUDSPEAKER
System type: active subwoofer with amplified stereo out
COMPONENTS
Low frequency: 2x8'' woofer/2''v.c.
FEATURES
Amplified subwoofer: Built-in amp LF 600 + MF/HF 2x300W 4Ohm
Adjustable crossover: LPF:80/165 Hz - HPF 22, 80,125 Hz
ACOUSTICAL SPECIFICATIONS
SPL cont/peak: 120/126dBdB @1m (free field)
Frequency response: 40/200Hz (±3dB)
Coverage angle HxV: ° omnidirectional
ELECTRONICS
Amplifier: Digital
Power: 600+2x300W /4Ohm
Input sensitivity: 4 dBu (1,228Vrms) adjustable
Protection: limiter temp.
User controls: mic, line, master, eq LF-HF
Operating voltage/frequency: 220 V~240 V/50 Hz
INPUT/OUTPUT CONNECTORS
Input signal: XLR IN/OUT, jack 6.35 mm, pin RCA unbal.
Output signal: 2 x 4 pole
Power connection: powerCON IN/OUT
CABINET CONSTRUCTION
Cabinet material: 15mm plywood
Sospension system: wall brackets (included)
PHYSICAL
Dimensions (WxHxD): 500x246x325mm
Weight: 14.5kg
