HMMA PLAY series is designed for all those PA applications where space is quite zero.
In half 19" Rack Unit there is a Class-D amplifier with powers ranging from 35W to 120W (70-100V or 4-16ohm outputs), a USB/BT/FM Radio with Remote Control, and a mixer for the control of the individual audio sources and the master.
It is also possible to connect these amplifiers to your alarm system and power a 24V in the event of a fire prevention system. Really the perfect solution for small business premises.
Specifications
| Rated Power |
120W @4ohm |
| Speaker Outputs |
100V or 70V & 4Ohms-8 Ohms-16 Ohms |
| Connectors |
Mic1 Input with unbalanced 6.3mm Jack; MIC2 with balanced XLR and Phantom Power; Line1-2 Inputs and Line Output with RCA |
| Knob Controls |
Microphone 1-2, Line1-2, MP3/FM, bass/treble and master |
| Sensitivity |
MIC 1&2 5mV; AUX 1&2 350mV; EMC 350mV |
| MIC frequency response |
180Hz-10kHz (±3dB) |
| AUX frequency response |
70Hz-16kHz (±3dB) |
| Noise |
<5mV (4 ohm load output terminal) |
| THD |
<1% 1KHz |
| Protection |
Short-Circuit, Clip, Overload and High-Temp Protection |
| Bass-Treble Adjustment |
10dB (±2) |
| USB Connection |
Type-B, Female |
| USB Drive Format |
FAT32 format –32GB Max |
| Player File Formats |
MP3 e streaming audio wireless BT |
| BT Receiving Distance |
10m |
| BT Standard |
BT2.1+EDR |
| Power Requirement |
AC~110-220V |
| Priority |
EMC > MIC1 > Others |
| Unit Size (W×D×H) |
247x198x66 mm |
| Packing size (W×D×H) |
343x302x121 mm |
| Net Weight |
3.0kg |
| Gross Weight |
3.7Kg |
