The XT series is a new generation of amplifiers offering high voltage output for high headroom sound, with 64 bit double-precision 96kHz DSP processing, and an advanced power management to squeeze the last watts out of your speakers.
It also offers similar power per channel in any impedance, exceptional power sharing in asymetrical loads and a powerful and fast response cooling system. The XT series has digital control with an extra large IPS display and touch screen panel user interface, making it easier and faster to use. The DSP management user functionalities include input routing matrix analog, input EQ section with 8 filters and 20 memories, input EQ user section, system preset selection, a snapshot library management with up to 20 presets and master control groups. The XT series has two Ethernet ports for daisy chain connection and access to the OCS software, designed to monitor the amplifiers in real time.
Spesifications
- Number of channels: 4
- Total output power: 6000 W
- Output power: @ 8 Omhs 4 x 1100 W
1 x 1200
@ 4 Omhs 4 x 1500 W
1 x 1900 W
@ 2 Omhs 4 x 1450 W
1 x 1450 W
@ 8 Ohms Bridged 2 x 3000 W
@ 4 Ohms Bridged 2 x 2900 W
Hi-Z 100V 4 x 800
Hi-Z 70 V 4 x 1500 - Max output voltage: 144 V peak
- Max output current: 38 A peak
- Total Harmonic Distortion: <0.05%
- Voltage Gain: 26 dB to 44 dB (1 dB step)
- SNR: 106 dB
- Required AC Mains: Operating Voltage (50 Hz – 60 Hz) 170V – 265V AC / 90V – 140V AC
- 1/8 Rated Power (@230V, 4 Ohms) 15 A
- Dimensions : W x H x D (mm) 483×89×320
W x H x D (inches) 19 x 3.5 x 12.5 - Weight: 8.5 Kg / 18.7 lbs
- Protections: Soft-start, Turn-on Turn-off transients, Multing at turn-on, Over-heating, DC, RF, Short-circuit, Open or mismatched loads, Overloaded power supply, ICL™, PMS™ and SSP™
