MCLELLAND AMP-D50Di Forsterker

Power Amplifier w/Dante Interface

Features

• Designed in Class D circuit.
• Provides 50W output power each channel at 8 Ohms.
• Dante slot card to receives the signal from Dante network.
• 12V Trigger In/Out for external control.
• Additional Line Out to drive another amplifier.
• Multiple modes to turn on amplifier.
• Universal Power Supply.
• Rack mount ears included.

Specifications

• Output Power:
• 50W @ 8 Ohms < 0.1% THD+N
• 65W @ 4 Ohms < 0.1% THD+N
• 120W Bridged @ 8 Ohms < 0.2% THD+N
• Impedance:
• Stereo mode 4 Ohms (minimum)
• Bridged mode 8 Ohms (minimum)
• Power Supply: 100VAC to 240VAC 50/60Hz, 400W
• Standby Power: ? 0.5 Watts
• Dimensions: 214mm x 249mm x 44mm (WxDxH)
• Weight: 1.8 K
• Dante Audio Interface
• Dante channel Receivers: 2
• Transmission rate: 100 Mbps
• Resolution: 16/24/32 Bit
• Sampling rate: 44.1 KHz, 48 KHz, 88.2 KHz, 96KHz
• Dante interface: RJ45 jack
• Power supply: PoE IEEE 802.3af
