FEATURES
WEATHERPROOF ENCLOSURE
With its weatherproof and dust-resistant enclosure this IP55-rated WPE version is ideal for outdoor use.
DUAL FOG OUTPUT
With its two nozzles, the maximum fog output is 200 m3 (7,063 ft3) per minute.
VARIABLE FOG OUTPUT
0-100% fog output control from your DMX/RDM device, or direct local control.
FLUID CONSUMPTION
At maximum output (2.76 bar / 40 psi) Me2 uses only 2 L (0.53 US gallon) of fluid per hour.
100% DUTY CYCLE
At all output levels Me2 produces a high-quality, consistent fog as long as there is fluid and gas.
NUMEROUS CONTROL OPTIONS
4-button LCD user interface, 3 standard USITT DMX512 channels, XLR-5 connectors, RDM compliant.
APS™ (AUTOMATIC PURGING SYSTEM)
This system purges the heating module after the first heating cycle and after every emission of fog preventing residual build up and clogging.
SPECIFICATIONS
Enclosure: Weatherproof and dust-resistant IP55-rated
Maximum fog output: 200 m3 (7,063 ft3) per minute
Fluid consumption: 2 L (0.53 US gallon) per hour at 2.76 bar/40 psi
Gas type: CO2 or N2
Gas consumption: 2.68 kg (5.90 lb) per hour at 2.76 bar / 40 psi
Control: 4-button LCD user interface, 3 standard DMX512 channels, XLR-5 connectors, RDM compliant.
Reservoir capacity: 2.5 L (0.66 US gallon)
APS™ (Automatic Purging System): Standard feature
Fog colour: Pure white
Particle size: 0.5 - 0.7 microns
Warm-up time: 8 minutes (maximum)
Fluid type: MDG Neutral
Voltage: 100 - 250 VAC, 50/60 Hz single phase
Power consumption: 1,415 W
DIMENSIONS
Length: 34 cm (13.4”)
Width: 48.8 cm (19.2”)
Height: 60.7 cm (23.9”)
Weight: 26.3 kg (58 lb)
Shipping weight: 35.4 kg (78 lb) with flight case
Approval: CE certified, CSA and UL approved
