FEATURES
LOW PRESSURE OR HIGH PRESSURE VERSIONS AVAILABLE.
LOW FLUID CONSUMPTION 90 ML (3.04 US FL OZ) PER MINUTE AT FULL OUTPUT.
ADJUSTABLE LOW FOG DENSITY. 100% DUTY CYCLE.
SELF-CONTAINED UNIT ON WHEELS FOR EASY TRANSPORT.
DETACHABLE REMOTE CONTROL AND 8 M (26 FT) CABLE INCLUDED.
COMPATIBLE WITH DMX INTERFACE AND REMOTE CONTROL TIMER.
THE QUIETEST LOW FOG GENERATOR ON THE MARKET CAN BE PLACED CLOSER TO THE ACTION.
SPECIFICATIONS
Fluid consumption: 90 ml (3.04 oz) per minute at full output
Liquid CO2 type: Low pressure version: refrigerated. High pressure version: non-refrigerated
Liquid CO2 consumption: Low pressure version: 3 L (0.79 US gallon) at 15.5 bar (225 psi) per minute. High pressure version: 2.77 kg (6 lb) at 60.3 bar (875 psi) per minute
Reservoir capacity: 2.5 L (0.66 US gallon)
Fog colour: Pure white
Particle size: 0.5 - 4.5 microns
CO2 running time: Low pressure version: 180 L (48 US gallon) canister (DEWAR) = 70 minutes. High pressure version: 35 kg (77 lb) canister = 13.25 minutes
Warm-up time: 8 minutes (maximum)
Fluid type: MDG Low Fog Fluid
Operating voltage (single phase): 208 VAC or 230 VAC, 50/60 Hz
Power consumption: 2,850 W
DIMENSIONS
Total length: 1.71 m (67 3/8“)
Operating length: 1.51 m (59 1/2”)
Width: 67 cm (26 3/8”)
Height: 78 cm (30 5/8”)
Weight: 113 kg (250 lb)
Approval: CE certified and ETL field approved
