FEATURES
FREE STANDING OR VARIABLE MOUNTING OPTIONS
UNIVERSAL SWITCHING POWER SUPPLY 100-250 VAC, 50/60 HZ, SINGLE PHASE
NOISE LEVEL AT 1 M (3.3 FT): 64DB AT MAXIMUM SPEED
4-BUTTON LCD USER INTERFACE, USITT DMX512, XLR-5 CONNECTORS, RDM COMPLIANT
ONE-CHANNEL STANDARD MODE OR TWO-CHANNEL QUIET MODE
VARIABLE SPEED AND AIR FLOW UP TO 24 M3 (850 FT3) PER MINUTE
SPECIFICATIONS
Electrical
100 - 250 VAC, 50/60 Hz, single phase, 100 W
Data
1 standard USITT DMX512 channel
2 XLR-5 connectors: 1 input, 1 output
Controllable through DMX + RDM
Digital Functions
Stand alone set speed
DMX Value
Accessory
Flight Case
Approval
Certified to CSA and UL standards, CE approved and RoHS compliant
Mechanical
3-bladed fan
270º tilt
Variable speed
M12 metric bolt hole
1/2” imperial bolt hole
Noise Level: 64db at full speed
2 handles
4-button controller with LCD panel
Airflow: up to 24 m3 (850 ft3) per minute
Omega clamp socket
Fan diameter: 26.4 cm (10.4”)
Total net weight: 6.8kg (15 lb)
Total net size: 38 cm (15”) H x 34.5 cm (13.58”) W x 25.4 cm (10”) D
