DEMOVARE!
Features:
Staggering 180,000 lumen output with 120* beam angle.
IP65 Rating
Graphic effects from 48 individually controllable groups of RGBW LEDs.
LIGHT SOURCE
Source: 1728x1W RGBW LEDs
CT: Full ON 6500K
Luminous Flux: 180'000lm
Lux: 3560lux @3m Full
Lux: 1281lux @5m Full
Source Life Expectancy: >30.000 h
OPTICS
Beam Angle: 120°
Field Angle: 155°
COLOR SYSTEM
Color Mixing: RGBW/FC
DYNAMIC EFFECTS
Rotating Gobos: Dynamic Patterns with speed and rotation control
Pixel Patterns: Preprogrammed dynamic and static patterns
FX Generator: Adjustable foreground/background color, index, speed, direction
Static Color Mode: Selection of static color
Manual Color Mode: Manual adjustment of color
Auto Mode: Built-in programs with execution speed adjustment
BODY
Body: Sturdy die-cast aluminium body conceived for long-time durability
Body Color: Black
CONTROL
Protocols: DMX512, RDM, Art-Net, Kling-Net
Pixel Control: 48 controllable sections
RDM: RDM ready for fixture remote monitor and settings
Display: Black OLED touch display
Firmware Upgrade: Yes, via USB-DMX interface (UPBOX1) not included
ELECTRONICS
Dimmer: Linear 0~100% electronic dimmer
Dimmer Curves: 4 Different dimming curves available
Strobe/Shutter: 1-30 Hz, electronic
Operating Temperature: -10° ~ +45°
ELECTRICAL
Power Supply: 100-240V – 50/60Hz
Power Consumption (at 230V): Strobe 1500W (peak) - Static 589W
Power Consumption (at 120V): Strobe 1550W (peak) - Static 602W
Output (at 230V): 2 units on a single power line
Output (at 120V): 1 units on a single power line
PHYSICAL
Signal Connection: 5p in/out, RJ45 in/out
Power Connection: Seetronic Powerkon True IP65 in/out
IP: 65 for outdoor events
Cooling: Forced air with low noise fan
Suspension And Fixing: Hanging bracket for floor positioning with "Quick-Lock" system
Dimensions (WxHxD): 468x179x268mm
Weight: 14.3kg
