Features
Can record 2048 IR codes. (there are 16 BANKs and 128 IR codes for each BANK)
Can save 100 scenes, each scene includes 16 sets of IR code.
With PC control software.
Can be controlled by ECP series control panel.
Specifications
Power: DC 12V
Protocol: EDX/DMX
Infrared Angle: 30 degree
Infrared Wavelength: 850nm
Digital signal input connector: 4-pin terminal
Digital signal output connector: 3-pin terminal
Dimension: 132(W) x 76(H) x 36(D) mm
Weight: 360g
