Features
•Six 1/4" TRS Headphone Outputs with Individual Level Controls
•Rear panel 6 1/4" TRS Stereo Insert jacks for individual use of each channel
•Up to 800 mW output per jack
•Stereo/Mono Switch allows mixing 2 mono signals
•Front panel 1/4" TRS stereo input jack
•DC to 30K Hz response for accurate sound reproduction
Specifications
•Input Impedance: 100K Ohms unbalanced
•Insert Impedance: 100K Ohms
•Max Input Level: +18 dBV
•Input Connectors: Stereo 1/4" phone front, L & R 1/4"
•Outputs: 6 1/4" stereo on front
•Max Gain: 20 dB/channel
•Maximum Output Power: = 800 mW per channel
•Output Impedance: 32 - 600 Ohms
•Mono/Stereo switch: Mixes L & R channels
•S/N Ratio: > 90 dB
•TH: < 0.08%
•IMD(SMPTE): < 0.08%
•Power: 115/230 VAC, 50/60 Hz, 15 VA
•Size: 19" L x 6" W x 1.75" H
•Weight: 2.2 kg
