Portable 4-Universe Console, Battery & Wireless Connectivity, 6 Playback Faders
EdgeGo is a portable lighting console designed for professional use on location or in the studio. It delivers four DMX universes, with output via wireless CRMX, XLR, or Ethernet (Art-Net/sACN). The hardware features a 10.1" touchscreen, 8 RGB encoders, 6 playback faders, and an HDMI output.
EdgeGo operates on V-Mount batteries or a 24 V DC supply, and its lightweight, fan-free chassis is built from reinforced polycarbonate to comply with carry-on luggage standards.
- Seamless Energy Source Switching: Automatically switches between power sources without requiring a restart.
- Extensive Fixture Library: Includes over 40,000 fixture types and a built-in fixture editor.
- Advanced Color Management: Accurate color calculations for up to 9 emitters using xyY data.
- Comprehensive Color Selection Tools: Features CIE Picker, HUE Picker, CCT Picker, faders, gels, and mood-based selection.
- Powerful Playback Engine: Unlimited simultaneous active cue lists, Tracking and non-tracking modes, Priority-based operation,
- Automatic synchronization of running effects
- Customizable Fader Layout: Configure faders, buttons, encoders, and push encoders to suit your workflow.
- MagicSheet Interface: Freely arrange and interact with fixtures, groups, labels, and images.
- Programmer Tools: Includes Fanning, Sub-Selection, Highlight, and Blind mode for efficient programming.
- Dynamic Effect Engine: Features predefined effects, preset-based effects, and a custom effects editor.
Technical specifications
CONNECTIVITY
- DMX out: 2 freely mappable
- ArtNet: 4 universes, freely mappable
- sACN: 4 universes, freely mappable
- MIDI: In / Through / Out
- Wireless: 2x DMX universes freely assignable to any of the TimoTwo LumenRadio modules — CRMX or W-DMX, with
- Bluetooth support
- External Display: 1 HDMI out
CONTROL SURFACE
- On-board Screen: 10.1” Full Color Touchscreen
- Playback Faders: 6 linear faders
- Playback Encoders: 6 rotary push-encoders with RGB backlight
- Value Encoders: 8 rotary push-encoders with RGB backlight
SOFTWARE
- DMX Channels: 2048ch
- DMX universes: 4 DMX universes freely mappable between CRMX, DMX, ArtNet, s-ACN
- Playback Pages: 99 + 1 Template Page
- Memories: 250 Presets per Feature Group, 100 Fixture-Groups
- Max Fixtures: Limited by DMX Channels
- External Control: MIDI trigger. MIDI Timecode, OSC
- Software update: via USB stick or online server (requires internet connection)
- Library update: via USB stick or online server (requires internet connection)
BODY
- Hardware on-board: Tilt adjustament bar
- Body: sturdy policarbonate body
- Body colour: black
ELECTRICAL
- Low Voltage DC mains: 24V via DC IN through external power supply, 14,4-28,8V with V-Lock batteries connection
- Max power consumption: 40W
- Standby power: 23 W
- BATTERY
- Battery: 24V compatible with external power supply and V-Mounts batteries (14.4-28.8Vdc) - battery not included
PHYSICAL
- Operating Temperature: 0° ~ +45°
- IP rating: 20
- Cooling: passive cooling and fan-free
- Data: 3 x USB ports (1 on the top, 2 on the back)
- Signal connection: 2 x Seetronic XLR 5p OUT connector
- Data connection: 1 x RJ45 IN/OUT
- Wireless Antenna: 2 RP-TNC female connector
- Low Voltage DC connector: XLR 4P for 24V, 2 x V-Mount adapter (14,4V)
- Dimensions (WxHxD): 374x98x356mm / 14.72''x3.86''x14.02''
- Weight: 4,1kg / 9.04lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, RCM
BOX CONTENT
- 1 x EDGEGO
- 1 x VDE15BEL010
- 2 x AEB2DBA
- 1 x external power supply
