EclDisplay is a range of revolutionary and flexible LED spotlights designed for galleries, retail and any public venue where an advanced but classical looking fixture is needed, with several control options, sources and optic versions available to precisely meet any application.
The EclDisplay CCFC is the version of the EclDisplay range made to be connected to an external Constant Current PSU and driver (max 4 x 1.4A/4.5V), selecting among the PROLIGHTS accessories or any third-party compatible component, leaving to System Integrators to install this luminaire in venues with their own wiring distribution and control. EclDisplay CCFC includes a high-efficiency 40W RGB + Warm White LED capable of delivering both a Full Colour spectrum and also tuneable White, and it is completed with a wide selection of optional zoomable profile or wash lenses, and other optical accessories like louvres and snoots, making it a truly a multi-purpose fixture.
Features:Constant Current version to be connected to external PSU and driver (max 4 x 1.4A/4.5V)
40W RGB + Warm White LED capable to deliver both a Full Colour generation and also Tunable White
Multiple lens options: zoomable profile or wash optics
LIGHT SOURCESource:
40
W
RGB + Warm White LED
Luminous flux:
(profile - 20°) 366 lm - (profile - 40°) 325 lm; (wash 2550 - min) 308 lm - (wash 2550 - max) 407 lm; (wash 1530 - min) 309 lm - (wash 1530 - max) 343
lm
@full
Lux:
(profile - 20°) 194 lx - (profile - 40°) 42lx; (wash 2550 - min) 49 lx - (wash 2550 - max) 20 lx; (wash 1530 - min) 119 lx - (wash 1530 - max) 58
lx
@5 m full
Source life expectancy:
> 50.000 hrs (L70B10 @Ta 25° C / 77° F)
OPTICSZoom:
(wash lens - optional) 15° ~ 30° or 25° ~ 50° - (profile lens - optional) 20° ~ 40
°
Other:
360° lens rotation - shutter blades lockable - optional 360° rotating barndoors and gel frame holder
Other:
(profile lens) shutter blades lockable
Other:
(profile lens - optional) manual rotating gobo holder size E, outer: 37 mm - image: 23 mm - thickness: max 3 mm
COLOUR SYSTEMColour mixing:
RGB + Warm White
ELECTRICALConstant Current mains:
max 4 x 1.4A/4.5V
Max power consumption:
30
W
PLCLD88050 40W RGB+WW LED Gallery light, Tunable White and FullColour, CC, ext. PSU&Driver
