JADE is the new hybrid Beam, Spot and Wash fixture conceived by Prolights to begin a new era of flexibility for automated moving fixtures. Equipped with Osram Sirius 280W HO short-arc lamp, JADE is surprisingly compact and ultra-light despite its high luminous flux, proving to be the perfect solution for rental companies. The special glass optic system has been engineered to grant a super-bright, sharp and crystal projection over the entire zoom range in both Beam mode 2°-10° and Spot mode 5,5°-23°. JADE also emulates a Wash fixtures by combining Zoom, Frost and any of the 13 color filters on board. The remarkable versatility of this projector is the result of a wide range of effect with unlimited possibilities: 2°-23° (1:12) zoom, 14 static gobos dedicated to Beam mode, 9 rotating glass gobos dedicated to Spot mode, 8way circular and 6way linear prysm, frost filter, 13 colors. Compact sized, bright to be used in arenas, featuring Beam, Spot and Wash, JADE is the solution for every light-show.
Lamp
Osram Sirius HRI 280W HO
Color temperature: 7800 K
Luminous flux: 11500 lm
Average life span: 2000h
Optics
HQ glass lens optics
Lamp featuring built-in parabolic reflector ensuring highest uniformity and precision
Focus: electronic focusing + autofocus
Zoom range: 2°-10° beam mode, 5.5°– 23° spot mode
Zoom speed: Beam: 2°-10° (1.8sec), Spot: 5.5°-23°(2.1sec)
Light output (Beam mode): 93850 lux @ 15mt, 2°
Light output (Spot mode): 2562 lux @ 5mt, 23°
Dimmer / shutter / strobe
0-100% linear dimmer
Independent shutter and fading effects with adjustable speed
Strobe: mechanical, 8 flash per second (with random strobe effect)
Color system
Color wheel with 13 dichroic filters + open, linear-step-less selection (1,98rps)
3200K + 5600K color temperature and UV filters
Bidirectional rainbow effect
Color bounce effect for sequential colors on the wheel
Effects
1st Gobo wheel: 9 dichroic rotating Gobos
2nd Gobo wheel: 14 metallic fixed Gobos
126 possible overlapping gobos combinations
"Gobo-shake" effect
“Gobo-scroll” effect with variable speed
Gobo change with synchronized blackout
Easy access to gobo wheels for replacement
8-facet circular prism effect, bi-directional rotation with variable speed
6-facet linear prism effect, bi-directional rotation with variable speed
Frost filter softening beam outlines
Auto & SoundActive show, with editable scenes from Menu with Master/Slave function
Electronics
Color LCD display with high resolution for simplified access to control menu, configuration and DMX addressing
Menu language: English, French, Spanish
4 DMX configurations available: 14/16/22/23 channels for full flexibility and control
2,4GHz WDMX receiver by Wireless Solutions
Input and output signal through 3p and 5p XLR connectors
RDM ready to set DMX Address, Display Flip, X/Y Reverse and more settings
RDM monitors Voltage, Current, Power Consumption Of Lamp
Firmware Upgrade Via DMX
Hibernation When Lost DMX For Preset Time
Advanced diagnostic system for all PCBs, with thermal and fan rotation control
"ENERGY SAVE” mode: 50% reduction of power consumption during blackout status
Remote ON/OFF lamp control by DMX
Remote unit reset by DMX
Lamp life timer
Cooling: filtered forced ventilation with auto-change fan speed according to temperature
Temperature indication of base, arm, head
Battery backup for user operation without connecting to the main
Structure and moving body
Aluminium structure with hi-resistance poly-carbonate cover, black color
Ergonomic side handles for transportation
Motion Angle: Pan = 630° (2.8 sec) - 540 (2,1 sec), Tilt = 265° (1,8 sec)
Pan/Tilt resolution: 8-bit or 16-bit Pan = 2,47° Pan Fine = 0,0096° Tilt = 1,039° Tilt Fine = 0,004°
Feedback automatic repositioning
Suspension and fixing: any possible working position through omega kit (included) with “quick lock” system
Power supply
Electronic ballast: 100-240V 50/60Hz universal 500W power supply
Connections: PowerCON TRUE IN
Power consumption: 423W
Temperatura di esercizio: -20°C to 45°C
Protection: IP20
Weight and dimensions
Weight: 18 kg
Dimensions (WxHxD): 355x619x235 mm
