MINIECLFR is the LED replacement for a standard tungsten 300K fresnel. Featuring all the output characteristics of a traditional Fresnel, but with the added benefits of beam control, functional barn doors and a power source that focuses on outstanding colour rendition. The MINIECLFR adds all the advantages of the LED to the traditional Fresnel.
Features:
TU (3200K) and DY (5600K) versions available both with HD dimming
Fresnel lens with 15° to 55° manual zoom range
Truly silent operation making it perfect for studio and stage use
LIGHT SOURCE
Source: 1x38W LEDs
CT: (TU) 3050 K - (DY) 5000K
CRI: (TU) (15°) 92.2 - (55°) 92.1 - (DY) (15°) 82 - (55°) 81.9
R9: (TU) (15°) 65.3 - (55°) 64.5 - (DY) (15°) 9.4 - (55°) 8.5
Luminous flux: (TU) (15°) 853.77 lm (55°) 2005.9 Im - (DY) (15°) 1349.4 lm (55°) 2840.6lm
Lux: (TU) (15°) 744 lux - (55°) 258 lux - (DY) (15°) 978 lux - (55°) 348lux @3m
Lux: (TU) (15°) 267.4 lux - (55°) 92.88 lux - (DY) (15°) 352.08 lux - (55°) 125.28lux @5m
Source life expectancy: >50.000 h
OPTICS
Zoom: 15°-55° manual
Beam angle: 15°-55°
Field angle: 29°-78°
Lens diameter: 3.93''-100mm
Lens type: fresnel lens
Other: spigot not included; gel frame and barndoors included
COLOUR SYSTEM
Macros: several pre-build macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode: selection of static dimmer
Manual colour mode: manual adjust of dimmer throught menu and knob
Auto mode: built-in programs with execution speed adjustment
BODY
Body: aluminium die-casting
Body colour: black
CONTROL
Protocols: DMX512, RDM, Local knob
DMX channels: 1 / 2-1 / 2-2 / 3 / 5channel
RDM: RDM ready for fixture remote monitor and settings
Display: black OLED high resolution display
Firmware upgrade: yes, via USB-DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain
Other: 16bit control of dimmer
ELECTRONICS
Dimmer: linear 0~100%, manual knob dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 28 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free frequency with adjustable PWM
Selectable PWM: 600~25K Hz
ELECTRICAL
Power supply: 100-240V – 50/60Hz
Power consumption (at 230V): 33.2W
Power consumption (at 120V): 31.8W
PHYSICAL
Cooling: natural cooling of the peculiar chassis and to absence of fans
Sospension and fixing: hanging bracket suitable for safe hanging and positioning
Signal connection: DMX 5p IN/OUT
Power connection: 16A Shuko plug
IP rating: 20
Dimensions (WxHxD): 203x191x279mm
Weight: 2.38kg
