NB! STRØMKABEL LEVERES UTEN STØPSEL. SE TILBEHØR FOR ALTERNATIVER
MINIECLFRFC is an advanced LED replacement for the traditional 300K Fresnel lamps. Offering 4 colour mixing, delivering high precision reproduction of the white spectrum from 2800 to 8000K with high CRI and extensive colour reproduction.
The optical system harnesses the power of a 68W custom LED with 4 colours to create an even projection, beautiful colours and precise whites.
Featuring HD dimming and tuning from 2800K to 8000K version, the MINIECLFRFC delivers the performance and quality of output demanded from this level of light.
Features:
Tunable white 2800-8000K with high CRI
RGB + lime full colour mixing to achieve any colour palette
Silent operation for studio and stage use
LIGHT SOURCE
Light source: 68 W RGB + lime LEDs custom LED engine
Source: 68W RGB + lime LEDs
CT: 2800 K - 8000K
CRI: (15°) 63.9 - (75°) 66.6
R9: (15°) 52.9 - (75°) 44.8
Luminous flux: (15°) 164.63 lm - (75°) 705.72lm
Lux: (15°) 103 lux - (75°) 49,9lux @3m full
Lux: (15°) 37 lux - (75°) 18lux @5m full
Source life expectancy: >50.000 h
OPTICS
Zoom: 15°- 75° manual
Beam angle: 15°- 75°
Field angle: 39°-112°
Lens diameter: 3.93''-100mm
Lens type: 18° lens on board
Additional optics: 20° filter on board
Other: spigot not included; gel frame and barndoors included
COLOUR SYSTEM
Colour mixing: RGBL
CTC: amber shift activation by menù and DMX
White presets: 2800K - 8000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
CONTROL
Protocols: DMX512, RDM
DMX channels: 2 / 3 / 4-1 / 4-2 / 5 / 6 / 7 / 9-1 / 9-2 / 12 / 14channel
RDM: RDM ready for fixture remote monitor and settings
Display: black OLED high resolution display
Firmware upgrade: yes, via USB-DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain
Other: 16bit control of dimmer and colour
ELECTRONICS
Dimmer: linear 0~100% electronic dimmer
Dimmer curves: 4 different dimming curves available
Strobe / shutter: 1 - 30 Hz, electronic
Operating temperature: -10° ~ +40°
Flicker: flicker free frequency with adjustable PWM
Selectable PWM: 600~25K Hz
ELECTRICAL
Power supply: Input:100-240VAC,(50-60 HZ)Output:DC 48V 1A 100-240V – 50/60Hz
Power consumption (at 230V): 25,1W
Power consumption (at 120V): 25,9W
Power factor: 0.58/120V - 0.55/230V
PHYSICAL
Cooling: natural cooling of the peculiar chassis and to absence of fans
Sospension and fixing: hanging bracket suitable for safe hanging and positioning
Signal connection: DMX 5p IN/OUT
Power connection: 16A Shuko plug
IP rating: 20
Dimensions (WxHxD): 203x191x279mm
Weight: 2.52kg
