NB! Strømforsyning ikke inkludert. Se tilbehør for kompatibel vare
This relay hub consists of 12 relays with isolated sets of voltage free contacts that close on operation. The relay hub can be used in three ways:
1. Direct connection via Cat5/6 UTP cable to the A 6500 wallplate, which is programmed to control relay activation.
2. As an expansion to the A 6505 hub, increasing the total number of relay contacts from 3 to 15. In this configuration, one of the serial outputs of the A 6505 would be used to control the A 6510. These hubs should be located as close together as possible.
3. As a standalone serial controlled relay hub for use with any third party system utilising RS232/485.
Requires 24V DC input. Will provide power to A 6500 wallplate if connected.
Size: 66W x 131W x 29H inc flanges.
