Self-respecting musicians …
Advantages:
- Semi-transparent soft jacket design ensures a high number of bending cycles
- Gorgeous velvet look with soft touch feeling
- Dual shielding by flat helical Cu mesh and carbon semiconductor
- High bending cycles
- Zero-twist winding
Application:
- High-end guitar cable for pure transmission even over longer distances
- Perfect for the unbalanced studio cabling
Specifications:
| Article number | 300-0351 |
|---|
| Name | SC-SPIRIT BLACK ZILK |
|---|
| EAN | 4049371191845 |
|---|
| Properties | OFC oxygen free copper |
|---|
| Properties | Analog |
|---|
| Application area | Studio / Broadcast |
|---|
| Application area | Mobile outdoor / indoor |
|---|
| Application area | Stage / live |
|---|
| Application area | Installation |
|---|
| Application | Instrument Cable |
|---|
| Colour | black, semi-transparent |
|---|
| Colour detailed | black, semi-transparent |
|---|
| Signal transmission | asymmetrical |
|---|
| Construction | LI2Y(LS)DY1x0,25mm² |
|---|
| Jacket material | PVC |
|---|
| Jacket material (audio) | transp. PVC |
|---|
| Jacket Ø mm | 7,20 |
|---|
| Number of Channels (audio) | 1 |
|---|
| Inner conductor (audio) | 1 |
|---|
| Inner conductor (audio) mm² | 0,25 |
|---|
| Inner conductor Ø (audio) mm | 0,56 |
|---|
| AWG (audio) | 24 |
|---|
| Shielding | Copper braided shielding + semiconductor |
|---|
| Shielding factor % | 100 |
|---|
| Copper strands (audio) | 32 |
|---|
| Copper strand Ø (audio) mm | 0,10 |
|---|
| Conductor insulation material | Foam / Skin-PE |
|---|
| Weight per 1 m g | 64 |
|---|
| UV-resistant | yes |
|---|
| Fire load per m kWh | 0,26 |
|---|
| Style variant | round |
|---|
| Packing | 100 m |
|---|
| Temperature min. °C | -30 |
|---|
| Temperature max. °C | 70 |
|---|
| Width mm | 7,2 |
|---|
| Height mm | 7,2 |
|---|
| Capac. cond./shield. per 1 m (audio) pF | 80 |
|---|
| Capacity wire/electic screen at 1 ft. (audio) pF | 24,384 |
|---|
| Insulation resist. per 1 km GO | 1 |
|---|
| Insulation resist. per 1000 feet GO | 0,3048 |
|---|
| Insulation resist. per 1 km (audio) GO | 1 |
|---|
| Insulation resist. per 1000 feet (audio) GO | 0,3048 |
|---|
| Conductor resistance per 1 km O | 90 |
|---|
| Conductor resistance per 1000 ft. O | 27,432 |
|---|
| BPVo-Euroclass | Fca |
|---|
