High-power processor for glitch-free data conversion, patching and merging of up to 16 Universes
Powerful yet intuitive feature set, control, management, via on-board LCD, Browser Interface, or ProPlex Software
Full-featured ProPlex Software option for management of the largest networks
Dual EtherCon ports allow very low latency linking of units and, with GBS and EZ-LAN, ring topology for speed and redundancy
PoE power-in option for convenience or dual-power redundancy
Merge ArtNet or Streaming ACN from multiple sources
Full bi-directional RDM functionality. Input or output on any DMX connector.
Rugged, tour-ready ProPlex “Blue Box” construction
Technical Specifications
Part Number: PPIQB161625RR
Ethernet Ports: 2
ArtNet/sACN Universes: 16 max.
DMX Ports: 16
DMX Connectors: Neutrik XLR5 Female
DMX Port Isolation: Optical, up to 1000V
Ethernet Connector: Neutrik EtherCon RJ45
Network Protocols: ArtNet, sACN (E1.31)
Power: 100-240V, 50-60 Hz / PoE In (802.3af)
Power Connector: Neutrik PowerCon NAC3MPA
Power Consumption: 20 W
Fuse: 1 A, 250 V
Operating Temp.: -20º to +40º C
Unit Dimensions: (WxHxD) 19 x 3.5 x 8 in [483 x 90 x 205 mm]
Unit Weight: (unpacked) 8.4 lb [3.8 kg]
Shipping Dimensions: (WxHxD) 21 x 8 x 16 in [533 x 203 x 152 mm]
Shipping Weight: 10.9 lb [4.9 kg]
