CHAMSYS MagicQ MQ70 Compact Console

24 univers. 10,1" skjerm Cover/lampe ink

Varenr: 100-075-CH
70 396,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om forhandlerstatus.
1 på lager i Oslo
BeskrivelseLenker & dokumenter
Beskrivelse

MagicQ MQ70 is the latest offering in the Compact Console range of small and lightweight consoles that you can fly with. The MagicQ MQ70 fits within hand luggage carry on restrictions of all the major budget airlines including, Southwest, Easyjet and Ryanair. The console features a 10.1” Multi touch display, with illuminated encoder and fader tracks.

The console supports 24 universes with an option to expand to 48. The console has 3 network ports enabling ArtNet and sACN direct from the console, whilst also having 4 assignable physical DMX ports. This feature packed console also includes WIFI inbuilt to the console for quick connection to ChamSys MagicQ Remote focus application without the need for external networking hardware.

The MQ70 features an inbuilt UPS which protects both the console and the Ethernet switch in case of power fail. It has low power consumption and does not require a cooling fan - enabling silent operation making it the ideal choice for touring shows, broadcast, theatrical and corporate shows.

With built in MIDI input and output, LTC and audio input for synchronization, the MagicQ MQ70 provides many options for integration with show control and audio systems.

The MagicQ MQ70 runs the same MagicQ software as other MagicQ consoles, meaning that shows programmed on it can be loaded and ran on any other MagicQ console (within the universe limits).

  • Universes supported: 24 *expandable to 48
  • Channels: 12288 *expandable to 24576
  • Number of fixtures: Up to 12288 *expandable to 24576
  • Cues: 5000
  • Groups: 5000
  • Display: 10.1” Touch Screen: Multi touch
  • DMX 5-Pin XLR: 4
  • Faders: 12
  • Attribute encoders: 8
  • Network ports: 3
  • Inbuilt WIFI: Yes
  • USB ports: 5
  • Audio in: Yes
  • Audio out: Yes
  • MIDI: Notes, TC, Show Control
  • LTC in: Yes
  • Remote input port: Yes
  • Illuminated faders: Yes
  • Illuminated encoders: Yes
  • Wing Support: Yes
  • Multi console: Yes
  • 1 Dual Colour Dimmable LED
  • Console Lamp
  • UPS: Yes
  • Width: 525mm (20.6”)
  • Depth: 350mm (13.7”)
  • Height: 60mm (2.3”)
  • Weight: 7kg (15.4lb)

MagicQ Software
MagicQ software offers powerful lighting control with loads of features that lighting designers have some to rely on, such as full lighting visualisation, pixel mapping, and HD media playback on up to 8 different layers, all integrated smoothly to streamline workflows, save time, and shorten learning curve.
