Bass reflex passive subwoofer, 400 W AES,122dB SPL

Features:
Low frequency: 2x8'' woofer/2'' v.c.
Frequency response: 40-200 Hz (±3dB)
ARK2V8SP subwoofer speaker is the ideal complement to column loudspeakers for reinforcing low notes.
Signal connection between the subwoofer and medium-high column units via a connector integrated with the loudspeaker.
The DAD logo on the grille can be rotated rapidly for the both vertically and horizontally installation.
Birch plywood enclosure.

LOUDSPEAKER
System type: passive subwoofer

COMPONENTS
Low frequency: 2x8'' woofer/2''v.c.

FEATURES
AES/program power: 400/800W
SPL max: 122dB @1m (free field)

ACOUSTICAL SPECIFICATIONS
Sensitivity: 93dB @1W/1m (free field)
Impedance: 8
SPL cont/peak: 116/122dB @1m (free field)
Frequency response: 40-200Hz (±3dB)
Coverage angle HxV: ° omnidirectional
Suggest LPF range: 100/160Hz
Recommended amplifier up to: 800W

INPUT/OUTPUT CONNECTORS
Input signal: jack 6.35 mm, NL4 IN/OUT

CABINET CONSTRUCTION
Cabinet material: 15mm plywood
Sospension system: support with signal connection
Handles: 1 top

PHYSICAL
Dimensions (WxHxD): 260x660x365mm
Weight: 17.1kg
