In this fast-paced market, the AlphaPix 2 family keep ahead of the game by consistently delivering top-quality images with the latest high-resolution indoor LED displays. The AlphaPix 2 family use black-faced SMD LED for high-contrast and superb colour consistency in a robust, lightweight die-cast aluminium housing. The frame and fast interlocking system create a seamless image with minimal setup time. To deliver the perfect image, the AlphaPix 2 series features a high refresh-rate, advanced greyscale properties and automatic image correction along with a viewing angle of up to 160°.
Features:
Rental-friendly die-cast aluminium housing
Black-face LED for high-contrast and superb colour consistency
Magnetic front access LED display modules for fast and easy maintenance
Flicker-free on camera
High-performance video reproduction at every level of brightness
160° viewing angle
CE and EMC certified by TUV
VIDEO
LED source: SMD 2020 high-power FC black face
Pixel pitch: 2,97mm
Panel resolution: 168x168pixels
Module resolution: 84x84pixels
Luminous flux: 1.000nit
Grayscale: 16 bit
Refresh rate =: 3.840Hz
Drive Mode: 1/16 scan, constan current
Vertical viewing angle: 160°
Horizontal viewing angle: 160°
LED density: 112.896LED/sqm
Dead Pixel Ratio: <0,002
LED avg life span: 100.000
ELECTRICAL
Power input/output: powerCON
Power supply: AC 110/230 V 50/60 Hz
Max power consumption (panel): 130W
Avg power consumption (panel): 45W
Max power consumption (sqm): 520W
Avg power consumption (sqm): 180W
Standby power consumption (pannello): 10,8W
Max rated current/panel:: AC 220 V / 0,6 A
Max power output: 8modules
Working temperature: -10 ~ +40°C
Working humidity: 10 - 90%
CONTROL
Control protocol: Novastar
Signal input: RJ45
Signal output: RJ45
MECHANICS
Module size (WxH): 250x250mm
Panel size(WxHxD): 500x500x90mm
Vertical hanging system: built-in aliscaf clamp support
Cooling: natural cooling of the peculiar chassis and to absence of fans
Connection: seamless locking system
Body: die-cast aluminium housing
Color: black
IP rating: IP40
Panel weight: 8kg
Weight per square meter: 32kg
Hanging Panel Quantity =: 20
Compliant Standard: CE
