NB! STRØMKABEL LEVERES UTEN STØPSEL, SE TILBEHØR FOR ALTERNATIVER
Eclipse FS is a full colour elipsoidal LED, designed to deliver a full range of pastels, saturates and whites, both with or without gobos. The Eclipse FS’ RGB + Lime LED engine has been specially engineered to provide a full spectrum and full output in the most discerning environments, regardless of which role the Eclipse FS is playing.
Features:
RGB + Lime ellipsoidal LED with HD dimming and extensive colour palette
High definition optics for sharp focus and gobo projection
Accepts industry standard accessories
LIGHT SOURCE
Source: 91x3W RGB + lime LEDs
CCT: @full - 5.000K
CRI: @full in STUDIO mode - 82 / @full in HB mode - 70
Luminous flux: (26°) 6'262 lm at STUDIO mode - 6'524 lm at HB mode
Lux: (14°) 8'090 lx - (19°) 7'020 lx - (26°) 4'960 lx - (36°) 2'610 lx - (50°) 1'190lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: optional 14° / 19° / 26° / 36° / 50°
Lens type: high-quality glass lens optics
Focus: manual
COLOUR SYSTEM
Colour mixing: RGB + lime / full colour
CTC: CTC control through dedicated DMX channel, + / - green and magenta correction and amber shift activation by DMX
White presets: 2.700 K ~ 10.000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build pixel macros with adjustable speed
DYNAMIC EFFECTS
Shutter system: 3 layers blades system and fast rehabilitation of blade in case of out of frame blade
Gobo size: B, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
Special features: HB mode, STUDIO mode, SILENT mode and linear crossfade from a white to any color and CTO applied on colours
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
CONTROL
Protocols: DMX512, RDM
DMX channels: 1 / 2 / 3RGB / 4RGBL / 5RGBL / 3 / 4 / 5 / 8 / 13 ch - Tungsten / 3.200 K / 5.400 K / 6.500 K / Theatrechannel
RDM: RDM ready for fixture remote monitor and settings
Display: black OLED high resolution display
Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -20° ~ +45°
Flicker: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 220W
Power consumption (at 120 V): 220W
Output (at 230 V): 10 units on a single power line
Output (at 120 V): 5 units on a single power line
PHYSICAL
Cooling: low noise fan
Sospension and fixing: hanging bracket suitable for safe hanging and positioning
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 265x259x540mm
Weight: 10kg
