Safe and reliable full isolation design

• DMX phase dimmer, trailing edge dimming
• Supports resistive loads and capacitive loads
• Standard DMX512 compliant control interface
• RDM function enabled to realize intercommunication between DMX master and decoder.
• For example, DMX decoder’s address can be assigned by DMX master console
• With digital display to show data directly, easily to set and show DMX address
• DMX channel quantity from 1CH~4CH settable
• Output dimming curve gamma value from 0.1 ~ 9.9 settable
• 4 channels AC100-240V output
• To dim single color dimmable LED lamps, dimmable LED driver, traditional incandescent and halogen lights
• Din rail installation, easy and fast
• Waterproof grade: IP20

For øvrige tekniske spesifikasjoner se datablad under "Lenker & Dokumenter"
