AUDIOPHONY PREZONE444 Sonemikser

Mixing desk- 8 channels 4 independent output zones
Each input can be sent to the zone of your choice
Compatible with the WP1 wall-controller
Compatible with MIC-DESK4

• 4 symmetric Mic/Line inputs via XLR or Jack 6.35 (TRS)
• 4 stereo inputs via RCA or mono via Jack 6.35
• 4 symmetric link out outputs per zone via Phoenix plugs
• Balanced link output via Phoenix plug
• Microphone priority via input 1
• Phantom power supply for inputs 1 to 4
• Gain and tone settings (3 ways) for channels 1 to 4
• Gain settings via stereo inputs
• Tone settings (2 bands) per zone
• RJ45 Connector for WP-1 (remote input) wall controller and MIC-DESK (remote mic) for each zone
• Global Contact Mute
• Assign zones 1 to 4 to each input
• Peak and Signal display for each input
• Output display for each zone via 5-LED VU meter
• Headphones output with volume control (zones and PFL)
• Front monitoring speaker
• Screwdriver required to access technician-level settings
• Power supply: 230 V 50/60 Hz, and 24V DC
• Power consumption: 30 Watts
• Back-up power supply: 24V, DC with Link Out
• Frequency response: 20Hz ? 20KHz (+/-3 dB)
• T.H.D (1 kHz nominal power): < 0.1%
• Equalizer:
- High : +/-15 dB @ 12kHz
- Mid : +/-15 dB @ 2.5 kHz
- Low +/- 15 dB @ 80 Hz
• Dimensions: 320 x 088 x 482 mm
• 19?? Rackable
• Height: 2 units
• Weight : 5 kg
