2-way passive loudspeaker, coaxial design, 300 W AES, 128dB SPL

Features:
Low frequency: 12'' woofer/3'' v.c.
High frequency: 1'' driver / 1.7'' v.c.
Frequency response: 50-18000 Hz (±3dB)
ARK12MP full range speakers are suitable for mediuim and large installations or can be used as satellites in combination with the passive or active sub.
The DAD logo on the grille can be rotated rapidly for the both vertically and horizontally installation.
Birch plywood enclosure.

LOUDSPEAKER
System type: passive 2 way coaxial design

COMPONENTS
Low frequency: 12'' woofer/3''v.c.
High frequency: 1'' driver/1.7''v.c.

FEATURES
AES/program power: 300/600W
SPL max: 128dB @1m (free field)

ACOUSTICAL SPECIFICATIONS
Sensitivity: 98dB @1W/1m (free field)
Impedance: 16 Ohm
SPL cont/peak: 122/128dB @1m (free field)
Frequency response: 50-18000Hz (±3dB)
Coverage angle HxV: 80x80°
Cross over frequency: 2200Hz
Protection: H.F. signal compression
Suggest HPF range: 80/120Hz
Recommended amplifier up to: 600W

INPUT/OUTPUT CONNECTORS
Input signal: Phoenix - NL4 IN/OUT

CABINET CONSTRUCTION
Cabinet material: 15mm birchplywood
Sospension system: wall brackets (included)

PHYSICAL
Dimensions (WxHxD): 450x361x450mm
Weight: 21.9kg
