DROP6i
DROP6i is a 2-way full-range 6.5" pendant loudspeaker delivering 75W @ 8 ohm, with a sleek discreet aesthetic, 70/100V line transformer with selectable power taps.
Main features
- Two-way full-range pendant loudspeaker
- 75 W RMS @ 8 ohm
- 6.5" woofer / 1" Silk Dome tweeter
- Compatible with high impedance (70V/100V) and low impedance (8 ohm)
- Power selector: 60/30/15/7.5W (Hi-Z) or 75W (8 ohm)
- IP53 rated
- ABS reinforced with fibreglass
- Paintable grill and speaker (white)
- INPUT/LINK double Euroblock connector
- Cable length 5m (2 height-adjustable steel cords)
- Available in white (RAL9003) and black (RAL9005)
- EASE files available
Technical specifications
- Effective Freq. Range: 70 Hz-20 kHz (-10dB)
- Coverage angle/Dispersion: 135° Conical
- Power handling: 75W RMS / 300W Peak
- Sensitivity: 90 dB (1W/1m)
- Maximum SPL: 109 dB continuous / 115 dB peak
- Power options (Hi Z Multi-tap): 70V/100V 7.5W-15W-30W-60W / 75W@8 ohm
- Recommended amplifier power: 150W RMS
- Ways: 2-ways full range
- Driver: 6.5" Woofer + 1" Tweeter
- Low frequency driver: 6.5" Woofer
- High frequency driver: 1" Silk Dome Tweeter
- Nominal impedance: 8 ohm
- Crossover filter: 1,65 KHz
- Connection type: Double INPUT/LINK connector, Euroblock type
- Power type selector: Back panel tap rotary selector
- Installation options: Pendant
- Environmental: IP53 rated
- Enclosure material: ABS reinforced with fibreglass
- Grille material: Aluminium
- Grille fixing system: Bayonet mount system
- Mounting system: Steel wire hanging
- Flying points: 2 x Steel wire hanging points
- Operating temperature: -20°C to 70°C
- Operating humidity: <85% HR
- Storage temperature: -20°C to 70°C
- Storage humidity: <90% HR
- Included accessories: 2 x Steel Wire for hanging (5m), 2 x 3C Euroblock connector
- Finished colour: White (RAL9003) or Black (RAL9005)
- Dimensions: 270mm x 344mm (ØxH)
- Weight: 4.2 Kg
- Pieces per box: 1
- Shipping dimensions: 380 x 325 x 370mm
- Shipping weight: 5.5 Kg
