NOVASTAR NOVAMRV360-1 Receiving card

Male connector on top

Varenr: NOVAMRV360-1-ML

Alt. varenr: NOVAMRV360-1

1 664,-eks. mva

Logg inn for å se dine nettopriser.
Ikke kunde? Søk om forhandlerstatus.

Tilkobling

Female connector on top

Female connector on bottom

Male connector on top

Male connector on bottom

Bestillingsvare, bestilles ved ordre. Ta kontakt for leveringstid.

Beskrivelse

Nova M3 MRV360 is one model of Nova receiving card. It has the interface of MOM(Memory On Module).
FEATURES

Single card outputs 16-group of RGBR 'data;
Single card outputs 20-group of RGB data;
Single card outputs 64-group of serial data;
Supporting MOM management, MOM can store calibration coefficient and the LED module information;
Single card supports resolution of 256x226;
Configuration file readback;
Temperature monitoring;
Ethernet cable communication status detection;
Power supply voltage detection;
Support high gray scale and high refresh rate;
Pixel-by-pixel brightness and chromaticity calibration, Brightness and chromaticity calibration coefficients for each LED;
Pre-store picture setting;
Able to connect monitoring card;
Comply with EU RoHs standard;
Comply with EU CE-EMC standard.
