PROLIGHTS MUSE70 Fresnel Moving head

800W 6Color LED, 7 - 60°, 200mm Lens

Varenr: 186041
Alt. varenr: MUSEF70CTP
81 080,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om å bli kunde her.
Bestillingsvare, bestilles ved ordre. Ta kontakt for leveringstid.

NB! STRØMKABEL LEVERES UTEN STØPSEL, SE TILBEHØR FOR ALTERNATIVER



800W 6 Color Moving LED Fresnel, 7° - 60° zoom with 200mm/8" lens


The Muse Fresnel70CT+ series represents a breakthrough in moving wash lights, available in multiple sizes and setting a new benchmark for Theatres, TV, and film sets of any scale. These fixtures combine the benefits of remote repositioning and beam control with the appeal of multicolored LED Fresnel fixtures.


The Muse Fresnel70CT+ model is equipped with a 6-color 800W light source and a 200mm/8-inch glass Fresnel lens. Its motorized zoom system offers a wide range from 7° to 60°. A key feature of this fixture is its internal 4-blade framing system on individual planes, enabling precise beam focusing. This, combined with its remote pan and tilt capabilities, facilitates an optimized workflow by eliminating the need for manual repositioning of static fixtures.


Driven by the PROLIGHTS Spektra OS, these units ensure consistency across fixtures, enhanced luminous flux in colors and whites with a broad color space and enriched light spectrum. These fixtures achieve unprecedented levels of CRI, TLCI, and TM30, making these fixtures a top choice whereas quality of light is required.


Designed for silent operation, the Muse Fresnel70CT+ series is perfectly suited for a variety of venues, from studios and corporate environments to live performances, where noise sensitivity is paramount.


SPEKTRA

  • Main features:
  • 800W 6 color Moving LED Fresnel, 28'800 lm
  • CRI: 97,2 @3.200K; 97,2 @5.600K - R9: 98,5 @3.200K; 97,5 @5.600K
  • Motorised zoom 7°-60°, 200mm/8'' glass lens
  • 1 color wheel, 1 ovalizer filter, 1 linear frost and iris
  • Internal framing system for precise beam focusing

Technical specifications


LIGHT SOURCE
  • Source: 800W 6 colour LEDs source with adjustable high color rendering
  • Luminous flux: (7,7°) 21'797 lm - (60°) 28'868 @5.600 K
  • Lux: (7,7°) 37'592 lx - (60°) 1'759lx @5 m 5.600 K
  • CRI: 97,2 @3.200K; 97,2 @5.600 K
  • R9: 98,5 @3200K; 97,5 @5.600 K
  • TLCI: 94 @3200K; 98 @5.600 K
  • TM30 Rf: > 95,3 @3.200K; > 94,4 @5.600 K
  • TM30 Rg: < 101,9 @3.200K; < 103,1 @5.600 K
  • Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
OPTICS
  • Zoom range: 7° - 60° motorised linear zoom
  • Lens diameter: 200mm / 7.87''
  • Lens type: AR-coated glass Fresnel lens providing a classic soft light fall-off
  • Focus: motorised 16-bit
COLOUR SYSTEM
  • Spektra OS: unmatched color precision and consistency
  • Colour control: XY, CCT, RGB, CMY, Gel Filters
  • Colour mixing: RGB / CMY / RAW
  • CCT: linear control from 2.200K to 15.000K with color-to-CCT linear crossfade
  • Tungsten Emulation: dimming with warm color shift simulation
  • Tint correction: ± green correction adjustment
  • Colour wheel: open+5 colour filters
DYNAMIC EFFECTS
  • Control Resolution: 16-bit dimmer and color control
  • Shutter system: 4 shutter blades with position and ±35° angle adjustment, ±45° rotation of the complete framing system
  • FX generator: ovalizer filter motorized with indexing and rotation
  • Frost: linear 0-100%
  • Iris: 5 - 100% motorised iris
CONTROL
  • Supported Protocols: DMX512, RDM, ArtNet, sACN (IGMP v2), CRMX
  • DMX channels: 35 / 40 / 41 / 46ch
  • Wireless Control: Included LumenRadio Timo Fx DMX/RDM receiver compatible with CRMX (Lumen Radio) and W-DMX (Wireless DMX)
  • RDM: for remote addressing and parameter configuration
  • Display: 2.4'' Color display
  • Firmware upgrade: via DMX with UPBOXPRO (not included) or via Ethernet with DMX-Workshop
MOVEMENT
  • Pan: 630° - 16-bit resolution
  • Tilt: 270° - 16-bit resolution
  • Absolute position: stationary reset without calibration movement
  • Position feedback: automatic repositioning after external movement
  • Pan / tilt lock: for transport and maintenance
ELECTRONICS
  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 5 selectable dimming modes available
  • Strobe / shutter: 1 - 30 Hz, electronic
  • Display battery: optional, self-charging battery backup
  • Selectable PWM: 600 to 40,000 Hz (selectable steps) with ±20% fine adjustment
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption (230V): 1400W
  • Output (at 230V): 2 units on a single power line
  • Power factor: > 0,94
CONNECTIONS
  • Signal connection: Amphenol XLR 5p IN/OUT connectors
  • Data connection: Amphenol RJ45 IN/OUT
  • Power connection: Neutrik powerCON TRUE1 IN connector
  • EtherFlow: Ethernet pass-through switch that preserves network connectivity even when the fixture is unpowered
PHYSICAL
  • IP rating: IP20
  • Cooling: heat pipe with low-noise fan
  • Housing: Aluminium structure with high-resistance polycarbonate cover
  • Finish: black
  • Operating temperature: Ta -10 to +45 °C (+14 to +113 °F)
  • Dimensions (WxHxD): 436x703x331mm / 17.17''x27.68''x13.03''
  • Weight: 29,3kg / 64.6lbs
INSTALLATION
  • Suspension and fixing: any position with quick-lock omega brackets
  • Hardware on-board: ancor points on the front for accessory mounting
  • Other: Handle on the top of the arm for easy transportation
CERTIFICATIONS / REPORTS
  • Compliance: CE
