NB! STRØMKABEL LEVERES UTEN STØPSEL, SE TILBEHØR FOR ALTERNATIVER
EclFresnel JrPTW is an advanced LED replacement of traditional 650 W Fresnel lamps, featuring 6 colour mixing delivering high precision reproduction of the white spectrum from 2.800 K to 10.000 K with high CRI and an extensive colour reproduction.
The optical system harnesses the power of a 130 W custom LED with 6 colours to create an even projection, beautiful colours and precise white, with added ability to apply +/- green and magenta correction to match other sources of light.
Featuring HD dimming and tuning from 2.800 K to 10.000 K version with external battery capabilities, the EclFresnel JrPTW delivers the performance and quality of output demanded from this level of luminaire.
Features:
Tunable white 2.800 K - 10.000 K with high CRI and extensive colour mixing
+/- green and magenta white tuning
Silent operation for studio and stage use
Battery ready, compatible with industry standard external batteries (optional)
LIGHT SOURCE
Source: 130W 6 colour custom LEDs source (red, orange, cyan, royal blue, green, lime)
CCT: 2.800 K - 10.000K
Luminous flux: (15,5°) 1'610 lm - (55°) 2'952lm @full
Lux: (15,5°) 709 lx - (55°) 145lx @5 m full
CRI: 91 @ 3200K; 92 @ 5600K
R9: 91 @ 3200K; 92 @ 5600K
TLCI: 86 @ 5600K
TM30 Rf: 88 @ 3200K; 86 @ 5600K
TM30 Rg: 106 @ 3200K; 104 @ 5600K
Source life expectancy: > 50.000 h
OPTICS
Zoom: 15,5° - 55° half peak angle
Lens diameter: 6'' - 150mm
Lens type: fresnel zoom lens
COLOUR SYSTEM
Colour mixing: tunable white + colour
CTC: CTC control, + / - green correction, Tungsten emulation
White presets: 2.800 K - 10.000K
Colour wheel: virtual colour wheel with macros
Macros: several pre-build macros with adjustable speed
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of intensity, CT, colour correction from knob
Auto mode: built-in programs with execution speed adjustment
Special features: linear crossfade channel from any white to any colour; virtual CTO on colours
BODY
Hardware on-board: filter frame, 8 doors barndoor, spigot
Pan angle: 360° with manual regulation
Tilt angle: 340° with manual regulation
Body: sturdy die-cast aluminium body
Body colour: black
Other: Spigot 28 mm
CONTROL
Protocols: DMX512, RDM, rotatory knob
DMX channels: 1 / 2 / 5 - 1 / 5 - 2 / 7 / 9 / 12 / 13 / 16 / 19 / 21channel
RDM: RDM ready for remote monitoring and settings
Display: Graphic User Interface
Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
Other: 16bit control of dimmer and colour
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Dimmer curves: 4 Selectable dimming modes available
Strobe / shutter: 1 - 30 Hz, electronic
LED Control: flicker free frequency with adjustable PWM
Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
Mains power supply: 100-240 V – 50/60 Hz
Max power consumption: 100W
Output (at 230 V): 23 units on a single power line
Power factor: >0,95
BATTERY
Battery: 29,6V 4400 mAh external battery (optional ECLFRSJBP4)
Re-charge connection: connection for external battery throught XLR 4p
Other: Voltage range: 22,4V-33,6V
PHYSICAL
Cooling: combination of heat pipe cooling system and low noise fan
Sospension and fixing: bracket for hanging and positioning
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 298x496x260mm
Weight: 7,5kg
