Advantages:
- Digital transmission over long distances due to the DMX and AES/EBU standards
- Excellent protection against electric interference (Cu mesh screen + AL/PT foil)
- Extremely robust due to the special tough jacket
Application:
- Networking of scanners and lighting systems with check-back function
- Connection of digital control units and devices of all kinds
Specifications:
| Article number | 540-0051 |
|---|
| Name | Binary 434 DMX512 |
|---|
| EAN | 4049371002387 |
|---|
| Properties | Analog |
|---|
| Properties | Digital 110 O AES / EBU |
|---|
| Properties | OFC oxygen free copper |
|---|
| Application area | Studio / Broadcast |
|---|
| Application area | Mobile outdoor / indoor |
|---|
| Application area | ELA 100 V |
|---|
| Application area | Stage / live |
|---|
| Application area | Installation |
|---|
| Application | DMX |
|---|
| Colour | black |
|---|
| Colour detailed | black |
|---|
| Signal transmission | symmetrical |
|---|
| Construction | 2(2LI2YS0,34mm²)(ST)CY |
|---|
| Jacket material | PVC |
|---|
| Jacket Ø mm | 7,00 |
|---|
| Number of Channels (AES/EBU, DMX) | 1 |
|---|
| Inner conductor (AES/EBU, DMX) | 4 |
|---|
| Inner conductor (AES/EBU, DMX) mm² | 0,34 |
|---|
| Inner conductor Ø (AES/EBU, DMX) mm | 0,66 |
|---|
| AWG (AES/EBU, DMX) | 22 |
|---|
| Shielding | Copper-cross mesh, tined + AL / PT foil |
|---|
| Shielding factor % | 100 |
|---|
| Copper strands (AES/EBU, DMX) | 7 |
|---|
| Copper strand Ø (AES/EBU, DMX) mm | 0,25 |
|---|
| Conductor insulation material | PE |
|---|
| Conductor insulation Ø mm | 1,70 |
|---|
| Weight per 1 m g | 65 |
|---|
| UV-resistant | yes |
|---|
| Fire load per m kWh | 0,22 |
|---|
| Style variant | round |
|---|
| Packing | 100 m spool |
|---|
| Temperature min. °C | -25 |
|---|
| Temperature max. °C | 70 |
|---|
| Width mm | 7 |
|---|
| Height mm | 7 |
|---|
| Capac. cond./cond. per 1 m (AES/EBU, DMX) pF | 58 |
|---|
| Capacity wire/wire at 1 ft. (AES/EBU, DMX) pF | 17,6784 |
|---|
| Capac. cond./shield. per 1 m (AES/EBU, DMX) pF | 100 |
|---|
| Capacity wire/electic screen at 1 ft. (AES/EBU, DMX) pF | 30,48 |
|---|
| Impedance O | 110 |
|---|
| Insulation resist. per 1 km GO | 5 |
|---|
| Insulation resist. per 1000 feet GO | 1,524 |
|---|
| Insulation resist. per 1 km (AES/EBU, DMX) GO | 5 |
|---|
| Insulation resist. per 1000 feet (AES/EBU, DMX) GO | 1,524 |
|---|
| Conductor resistance per 1 km O | 53 |
|---|
| Conductor resistance per 1000 ft. O | 16,1544 |
|---|
| Shield. resistance per 1 km O | 15 |
|---|
| Shield. resistance per 1000 ft. O | 4,572 |
|---|
| BPVo-Euroclass | Fca |
|---|
