You can rely on the NYM’s shielding...
Advantages:
- EMC shielding against electromagnetic interfering signals
- Complies with the VDE 0250, VDE 0482-332-1-2 / IEC 60332-1 standards and other requirements
- mobile application up to +5°C
Application:
- For all installations – especially in sensitive locations like e.g. hospitals, server rooms, studios
- For surface and flush mounting as well as wet rooms
Specifications:
| Article number | 720-0056-03025 |
|---|
| Name | (N)YM-(ST)-J |
|---|
| EAN | 4049371051811 |
|---|
| Properties | Analog |
|---|
| Properties | OFC oxygen free copper |
|---|
| Application area | ELA 100 V |
|---|
| Application area | Installation |
|---|
| Application | Power Lead |
|---|
| Colour | grey |
|---|
| Colour detailed | grey |
|---|
| Construction | (N)YM-(ST)-J |
|---|
| Jacket material | PVC, flame-retardant |
|---|
| Jacket material (power) | PVC, flame retardant and self-extinguishing |
|---|
| Jacket Ø mm | 10,90 |
|---|
| Number of Channels (power) | 1 |
|---|
| Inner conductor (power) | 3 |
|---|
| Inner conductor (power) mm² | 2,50 |
|---|
| Inner conductor Ø (power) mm | 1,78 |
|---|
| AWG (power) | 13 |
|---|
| Shielding | AL / PT-foil + Tinned drain wire |
|---|
| Copper strands (power) | 1 |
|---|
| Copper strand Ø (power) mm | 1,78 |
|---|
| Conductor insulation material | PVC |
|---|
| Weight per 1 m g | 208 |
|---|
| Style variant | round |
|---|
| Packing | bulk stock |
|---|
| Temperature min. °C | -40 |
|---|
| Temperature max. °C | 70 |
|---|
| Width mm | 10,9 |
|---|
| Height mm | 10,9 |
|---|
| Insulation resist. per 1 km GO | 0,02 |
|---|
| Insulation resist. per 1000 feet GO | 0,0061 |
|---|
| Insulation resist. per 1km (power) GO | 0,02 |
|---|
| Insulation resist. per 1000 feet (power) GO | 0,0061 |
|---|
| Test voltage V | 2000 |
|---|
| Nominal voltage (power) V | 500 |
|---|
| Operating voltage (power) V | 350 |
|---|
| Old article number | 720-0051-03025 |
|---|
| BPVo-Euroclass | Fca |
|---|
