SOMMER Magellan SPK Høyttalerkabel 2 x 2,50 mm², PVC Ø 6,00 mm, sort SOMMER Magellan SPK Høyttalerkabel 2 x 2,50 mm², PVC Ø 6,00 mm, sort

SOMMER Magellan SPK Høyttalerkabel

2 x 2,50 mm², PVC Ø 6,00 mm, sort

Varenr: 141667
Alt. varenr: 425-0201
60,-eks. mva
Logg inn for å se dine nettopriser.
Ikke kunde? Søk om forhandlerstatus.
Ledere
2 x 2,50 mm2
2 x 2,50 mm2
2 x 4,00 mm2
2 x 4,00 mm2
2 x 6,00 mm2
2 x 6,00 mm2

Dette produktet selges kun i hele ruller.

Tilgjengelige lengder:
SommerPacking
  • 100m
  • 500m
Bestillingsvare, bestilles ved ordre. Ta kontakt for leveringstid.
BeskrivelseLenker & dokumenter
Beskrivelse

Snow falls over the trees...

You know these promotional music sounds and voice infatuations. For this purpose we have the perfect cable: a coaxial cable is used where a small outer diameter is required in connection with a large wire cross-section. Especially for cable conduits where the speaker cable lies between cables which emit strong interferences. Normally a copper mesh shielding is used for coaxial cables. However, this will
render them unnecessarily stiff and inflexible, making multiple reeling almost impossible.
We use a dual reversely stranded helical Cu mesh screen for our SPK cables. This offers a better shielding than conventional copper braidings and makes the cable incredibly flexible.

When used as a speaker cable, the twisted screen is used as a second conductor. It has the same cross-section as the inner conductor.


Advantages:

  • Space-saving diameter due to coaxial construction
  • Excellent shielding due to the dual reversely stranded helical copper mesh screen
  • Highly flexible (PVC versions only) due to the special shielding design

Application:

  • For installation in building services engineering
  • Combination with small connectors (jack, XLR etc.)
  • High-end hifi applications


Specifications:

Article number425-0201
NameSC-Magellan SPK
EAN4049371005296
PropertiesAnalog
PropertiesOFC oxygen free copper
Application areaStudio / Broadcast
Application areaELA 100 V
Application areaInstallation
ApplicationSpeaker Cable
Colourblack
Colour detailedblack
ConstructionLI2Y(LS)DY2x2,5 mm²
Jacket materialPVC
Jacket Ø mm6,00
Number of Channels (audio)1
Inner conductor (audio)2
Inner conductor (audio) mm²2,50
Inner conductor Ø (audio) mm1,78
AWG (audio)13
ShieldingDouble copper spiral, counter-rotating
Shielding factor %100
Copper strands (audio)322
Copper strand Ø (audio) mm0,10
Weight per 1 m g73
UV-resistantyes
Fire load per m kWh0,18
Style variantround
Packing500 m spool
Packing100 m spool
Temperature min. °C-25
Temperature max. °C70
Width mm6
Height mm6
Capac. cond./cond. per 1 m (audio) pF150
Capacity wire/wire at 1 ft. (audio) pF45,72
Insulation resist. per 1 km GO0,2
Insulation resist. per 1000 feet GO0,061
Insulation resist. per 1 km (audio) GO0,2
Insulation resist. per 1000 feet (audio) GO0,061
Conductor resistance per 1 km O7,8
Conductor resistance per 1000 ft. O2,3774
Shield. resistance per 1 km O9
Shield. resistance per 1000 ft. O2,7432
BPVo-EuroclassFca
Lenker & dokumenter
Produsentens hjemmesideDatablad
