The CBR15 provides the lowest frequency in its lineup, delivering outstanding performance for
the front-of-house sound for live performance, DJ events or for installation situations that
require highly prominent low and high SPL.
Specifications
General specifications
Speaker type 2-way Speaker, Bass-reflex Type
Frequency range (-10dB) 46 Hz - 20 kHz
Nominal coverage H 90°
V 60°
Components LF 15" Cone, 2.5" Voice Coil (Ferrite Magnet)
HF 1.4" Voice Coil, Compression Driver (Ferrite Magnet)
Power rating NOISE 250W
PGM 500W
PEAK 1000W
Nominal impedance 8O
SPL Sensitivity (1W; 1m on axis) 96dB SPL
Peak (Calculated) 126 dB SPL
I/O connectors 1/4" Phone x 1, speakON NL4MP x 1
Dimensions W 455mm (17.9")
H 700mm (27.6")
D 378mm (14.9")
Net weight 17.7 kg (39.0 lbs)
Cabinet material Plastic
Finish Black
Handle Side x 2
Flying and mounting hardware Bottom x 2, Rear x 1 (Fit for M8 x 15mm Eyebolts)
Pole socket F35 mm Bottom x 1
Accessories Optional Speaker Bracket: BBS251, BCS251, BWS251-300,
BWS251-400
Crossover 2.0 kHz
