Integrating both lighting and media.

Travel Collection unlocks either Titan (lighting) or Prism (media), allowing you to preprogram and/or run your show on any Windows computer. T1+ has one physical DMX port, utilising your computer’s network and display ports for the other pots. T1+ unlocks 1,024 DMX channels within Titan or 1 display output and 1,024 DMX Pixels† from Prism.

Titan software.

• DMX CHANNELS PER DEVICE: 1,024
• CONTROL PROTOCOLS: DMX512 (E1.11)
• Streaming ACN (E1.31)
• MAX FIXTURES:           Unlimited
• 3D VISUALISATION:         Capture Engine
• USB WING SUPPORT:        1x D3 Wing, T3 Wing, or Titan Mobile Wing
• D3 TOUCH SUPPORT:       Yes (unlimited)
• MOBILE APP:           Yes - iOS & Android (“Titan Remote”)
• Art-Net & Art-RDM CITP
• GDTF (through Capture) MIDI over USB (MIDI
• Notes & MTC) Web API

TitanNet.

• EXPAND PROCESSING        Yes
• MULTI-CONSOLE SESSION      Yes
• OFFLOAD PROCESSING       Yes
• DMX CHANNELS PER SYSTEM     32,768

Prism software.

• DISPLAY OUTPUTS          1 (physical*, NDI or RTSP)     INPUTS               4 (physical*, NDI or RTSP)
• DMX PIXELS†               1,024†                   SURFACES              16
• LAYERS               16                  BLEND MODES            17
• BANKS               256                 ELEMENTS PER BANK         256
• MAX SURFACE RESOLUTION    8K / Super High Definition (SHD) square (7680px x 7680px)
• MAX OUTPUT RESOLUTION     4K / Ultra High Definition (UHD) square (3840px x 3840px)

  * the physical ports on a graphics card / capture card

†DMX Pixels coming soon to Prism. Each pixel can be 4 DMX channels (e.g. RGBW)
