Active loudspeaker, 2-way 150 W, 121dB SPL
Features:
Low frequency: 10'' woofer/1.5''v.c.
High frequency: 1'' driver/1.4''v.c.
Frequency response: 70/20000 Hz (±3dB)
Reproduction of voice and music for live and recorded performances
Cabinet designed for stage-monitor applications
Polypropylene box equipped with two side handles, one in the upper side and two wheels for the transport integrated
For portable PA systems, mobile DJ sets and voice/multimedia applications
LOUDSPEAKER
System type: active
COMPONENTS
Low frequency: 10'' woofer/1.5''v.c.
High frequency: 1'' driver/1.4''v.c.
FEATURES
Built-in amp: 150W /4Ohm
ACOUSTICAL SPECIFICATIONS
SPL cont/peak: 115/121dB @1m (free field)
Frequency response: 70/20000Hz (±3dB)
Coverage angle HxV: 90x45°
Cross over frequency: 3000Hz
ELECTRONICS
Amplifier: AB class
Power: 150W /4Ohm
Input sensitivity: 4 dBu (1,228Vrms) adjustable
Protection: limiter temp.
User controls: mic, line, master, eq LF-HF
Operating voltage/frequency: 230 V - 50 Hz
INPUT/OUTPUT CONNECTORS
Input signal: XLR/jack bal. pin RCA unbal
Power connection: VDE
CABINET CONSTRUCTION
Cabinet material: 4mm polypropilene
Sospension system: 35 mm mounting pole
Angle: 45° monitor applications
Handles: 2 on side, 1 top
PHYSICAL
Dimensions (WxHxD): 345x505x265mm
Weight: 9.5kg
