eGPA2-300
2x300 W RMS @4 ohm, high efficiency multichannel Class D amplifier with auto stand-by function and fanless design, 100% silent.
Main features
- Euroblock input and output connectors
- High efficiency, auto standby function and convection cooling (fanless, 100% silent)
- BRIDGE mode ready
- Thermal protection
- Overload protection
- Anti-clip system
Technical specifications
- Output channels: 2
- Output connection: Euroblock
- Output configuration: 2x300 W RMS @4 ohm
- Input channels: 2
- Input connection: Euroblock
- Max output @4 ohm: 310W
- @8 ohm bridge: 600W
- Input sensitivity: 0dB
- Input impedance: >20k ohm
- Frequency response: 20Hz-25kHz
- THD+Noise: <0.05%
- SNR: >85dB
- Crosstalk: >55dB
- CMRR: >55dB
- Damping factor: >150
- Power supply: Universal regulated SMPS with PFC
- Power 1/3 @4 ohm: 251W
- Power 1/8: 110W
- Idle: 26W
- Standby: 22W
- Amplification: Class D
- Efficiency: 87%
- Cooling: Convection (fanless)
- Protections: Short-circuit/Clip/Thermal Yes
- Filters: 15Hz 3rd order Butterworth HP
- Output settings: STEREO/MONO-BRIDGE (Lo-Z)
- Installation: 19" rack (1RU)
- Dimensions: 440x44x221mm
- Weight: 3.4kg
- Shipping weight: 4.6kg
