HSA2-400ES
Stereo amplifier with low and high impedance powered outputs (2x400W), high efficiency with auto stand-by for a true green profile (Energy Star certified).
Main features
- 2 mono balanced inputs (XLR and Euroblock)
- 2x400 W RMS output (4 ohm and 70/100V line level)
- Euroblock output connectors
- 2 REMOTE volume ports (0-10VDC), compatible with WPa series wall panels
- Energy Star certification
- High efficiency, auto stand-by function and convection cooling (fanless, 100% silent)
Technical specifications
- Output channels: 2
- Output connection: Euroblock
- Output configuration: 2x400W RMS (4 ohm and 70/100V)
- Input connection: XLR, Euroblock
- Max output @4 ohm: 350W
- @8 ohm bridge: 700W
- @100V: 400W @25 ohm
- Input sensitivity: 0dB
- Input impedance: >20k ohm (10k ohm unbalanced)
- Frequency response: 20Hz-40kHz
- THD+Noise: <0.05%
- SNR: >85dB
- Crosstalk: >55dB
- CMRR: >55dB
- Damping factor: >360 @8 ohm
- AC mains: 115V/230V@47-63Hz
- Power 1/3 @4 ohm: 334W
- Power 1/8: 143W/204VA
- Idle: 25W
- Standby: 0.5W
- Efficiency: 85%
- Cooling: Convection (fanless)
- Protections: Short-circuit/Clip/Thermal Yes
- GPIs: x2 (0-10VDC)
- Filters: 50Hz 3rd order Butterworth HP
- Output settings: Lo-Z/Hi-Z
- Installation: 19" rack (2RU)
- Dimensions: 482.6x88x373mm
- Weight: 16.4kg
- Shipping weight: 19.3kg
