VIC8X
VIC8X is an in-ceiling loudspeaker with an 8" woofer + 0.5" steerable tweeter, 60WRMS@8 ohm, including back can and tile bridge for flexible installation.
Main features
- 2-way false ceiling loudspeaker
- 8" polypropylene woofer
- 0.5" steerable tweeter
- Output 60WRMS@8 ohm
- 100V/70V line power selector: 60/30/15/7.5/3.75W
- Sensitivity (1W/1m) 93dB SPL
- Paintable magnetic metal alloy grille
- Plastic back cover (back can) included
- Includes tile bridge anchors for false ceiling mounting
- Dimensions (ØxD) 282x200mm
- Available in white (RAL9010) finish
- Weight 3.1kg
Technical specifications
- Effective Freq. Range: 75Hz-20kHz (-10dB)
- Coverage angle/Dispersion: 163° conical
- Power handling: 60W RMS/240W Peak
- Sensitivity: 93dB (1W/1m)
- Maximum SPL: 111dB continuous/117dB peak
- Power options (Hi Z Multi-tap): 100V: 60/30/15/7.5W/8 ohm, 70V: 60/30/15/7.5/3.75W/8 ohm
- Recommended amplifier power: 120W RMS
- Ways: 2 ways
- Low frequency driver: 8" woofer
- High frequency driver: 0.5" steerable tweeter
- Nominal impedance: 8 ohm
- Installation options: Ceiling
- Environmental: IPX4 rated
- Grille material: Magnetic, paintable metal alloy
- Operating temperature: Min -20°C/-4°F, Max 70°C/158°F
- Operating humidity: <85% HR
- Storage temperature: Min -20°C/-4°F, Max 70°C/158°F
- Storage humidity: <90% HR
- External diameter: 282mm/11.10in
- Internal diameter: 245mm/9.64in
- Recommended cut out diameter: 246mm/9.69in
- Required depth: 200mm/7.9in
- Ceiling thickness: 10mm/0.39in min, 50mm/1.97in max
- Included accessories: Back-can and tile bridge
- Finished colour: White (RAL9010)
- Dimensions: 282x200mm/11.1x7.9in (ØxD)
- Weight: 3.1kg/6.8lb
- Pieces per box: Pair
- Shipping dimensions: 300x240x585mm/11.81x9.45x23.03in
- Shipping weight: 7.0kg/15.43lb
