MIA-BR16

MIA-BR16 is a compact passive bass reinforcement unit designed as the low-frequency extension for MIA-40, with a ported 6" woofer delivering bass down to 61Hz.

• Compact passive bass reinforcement for MIA-40
• 6" woofer with moisture resistant treated paper cone
• Effective frequency range 61Hz-1.3kHz
• Power handling 80W RMS/320W Peak
• Sensitivity 91dB (1W/1m half-space)
• 8 ohm/70V/100V operation with multiple power taps
• MDF enclosure with painted aluminium grille
• IP44 rated, suitable for indoor and protected outdoor applications
• Surface or wall-mount installation options
• Rubber feet, wall brackets, drilling template and Euroblock connectors included
• Available in black (RAL9005)

• Effective Freq. Range: 61Hz-1.3kHz (-10dB)
• Coverage angle/Dispersion: 360°
• Power handling: 80W/160W Program/320W Peak
• Sensitivity: 91dB
• Maximum SPL: 105dB continuous/111dB peak
• Power options (Hi Z Multi-tap): 100V: 10/20/40/80W, 70V: 5/10/20/40W, 8 ohm: 80W
• Recommended amplifier power: 160W RMS
• Ways: Bass reinforcement
• Driver: Water resistant treated paper cone
• Low frequency driver: 1x6" woofer
• Nominal impedance: 8 ohm/100V
• Connection type: Euroblock type
• Installation options: Surface, Wall mounting
• Environmental: IP44
• Enclosure material: MDF
• Grille material: Painted Aluminium
• Grille fixing system: Press-fit mounting system
• Mounting system: Wall support system & support-legs
• Operating temperature: Min -20°C/-4°F, Max 65°C/149°F
• Operating humidity: <90% HR
• Storage temperature: Min -20°C/-4°F, Max 65°C/149°F
• Storage humidity: <90% HR
• Included accessories: 4x Rubber feet, 2x Supports for vertical mounting, 1x Wall support (large), 1x Wall support (small), 4x Wall plugs, 4x Wall screws, 9x Support screws, 1x Wall Drilling template
• Finished colour: Black (RAL9005)
• Dimensions: 350x290x150mm/13.78x11.42x5.91in
• Weight: 8.4kg/18.52lb
• Pieces per box: 1
• Shipping dimensions: 430x370x250mm/16.93x14.57x9.84in
• Shipping weight: 10.1kg/22.27lb
