Components LF: 12", 2,5" voice coil, Malt Cross Cooling System
HF: 1" Exit compression Driver , 1,75" aluminium voice coil
Frequency range 60Hz – 20 KHz (-10dB)
Frequency Response 66Hz – 18 KHz (± 3dB)
Max. SPL 127 dB
Coverage Angle 90º x 40º constant directivity horn. Rotatable
Power 1400 W Class D with switching power supply & PFC
LF Amplifier 1 x 800 W
HF Amplifier 1 x 600 W
Processing 96 KHz / 64 bit double precision DSP with FIR filters
Control User control interface with LCD
Control Connections USB (DSP programming)
AC Power 90 – 264V. 50/60 Hz with PFC
AC Connections 16 A Neutrik powerCON TRUE1 with looping output
Finish High resistant water-based black paint
Material 15mm Premium birch plywood
Dimensions (H x W x D) 639 x 370 x 386 mm
Weight 23,5 Kg (51.7 lbs)
